Smart Home Zigbee Gateway with 10 Inch Touchscreen IPS Panel – Amuse Tech Solutions
Android 10 smart device with IPS LCD display, dual-band WiFi, ZigBee 3.0, and multiple control options. Features RS485, dual relays, and Type-C USB, ideal for versatile installations in smart environments.
Description
Technical Specifications
| Operating System | Android 10.0 |
| Display Type | IPS LCD |
| Screen Resolution | 1280 x 800 |
| Touch Screen | G+G |
| Screen Size | ≥5.0 inch |
| Bluetooth | Yes |
| WiFi | Yes; 5G + 2.4G |
| ZigBee | Yes, ZigBee 3.0 |
| USB | Yes, Type C |
| Ethernet | 10 or 100M ethernet |
| TF Card | Yes, up to 32GB |
| Control Methods | Touch or knob or key |
| Power Supply | 100 to 240V AC |
| Other Features | RS485, Two Relays (L1, L2), Live or neutral line |
| CPU | CortexA53 1.5G |
| RAM | 1GB or 8GB |
| Installation Mode | Pre-embedded |
| Color | Grey |
| Working Temperature | 32.0°F to 104.0°F (0°C to 40°C) |
| Size (Appearance) | 11.38 in x 3.39 in x 0.43 in (289.05 mm x 86.11 mm x 10.92 mm) |
| Size (Install) | 3.39 in x 3.39 in x 2.76 in (86.11 mm x 86.11 mm x 70.10 mm) |
| Weight | 1.36 lb (0.616 kg) |
