Dual Band Zigbee WiFi Bridge Hub with 4G LTE & 2 LAN Ports – Amuse Tech Solutions
Dual-Band Zigbee 4G LTE Wi-Fi Bridge Hub Acts as a Bridge to Capture and Send Data from End Devices to the Cloud and Supports 1 Micro SIM Card Slot.
Description
Features
- Converts Cellular Network Data into WI-FI and Wired Network Port Data
- Supports 2 Gigabit LAN Ports
- 4GHz + 5GHz Dual-Band WIFI -AP
- Suitable for Home or Business Scenarios Requiring Wired Broadband Networks and WIFI Hotspots
- It can Work as the Bridge, Which Captures Data from End Devices
- Supporting Zigbee 3.0 and Sends it to the Cloud Via a Global Low-Power Cellular
Technical Specifications
| Chipset | MT7628AN + MT7612E+ EG25 Chip |
| CPU | MT7628AN Wi-Fi 2.4G, MT7612E Wi-Fi 5G (600 MHz) |
| OS | OpenWrt |
| Input Voltage Range | 4.5V to 5V DC |
| Power Adapter | 100V to 240V, 50Hz or 60Hz |
| Current | 350mA at 5V |
| Distance | 65.62 ft. (20 m) |
| Ram | Up to 128MB |
| Dual Band | 2.4 or 5 GHz |
| Speed | Up to 1200 Mbps |
| Supports Max Devices | 32 |
| Gigabit Ethernet Port | For Video Transmission of Multiple Cameras |
| Internal 4G LTE Antenna | 2 x 2.4G FPC Antenna, 2x 5G FPC Antenna |
| LTE Cat4 | 4G FDD-LTE B1, B3, B7, B8, B20 (2100, 1800, 2600, 900 or 800MHz), TDD-LTE B38, B39, B40, B41 (2600, 1900, 2300 or 2500MHz), 3G: DC-HSPA+ or HSPA+ or HSPA or UMTS, B1, B8 (2100 or 900MHz) |
| LAN or WAN Port | 1 x Micro SIM Card Slot |
| Network Interface | 1 1000Mbps LAN Ports, 1 1000Mbps |
| Power Seat Aperture | 0.138 Inches (3.5 mm) |
| Needle Diameter | 0.053 Inches (1.35 mm) Positive |
| Interface | 1 x WAN, 1 x LAN |
| Indicator LEDS | 1). Power LED Normally on When Powered on 2). Network LED Normally on When Connected 3). Wi-Fi LED Normally on After Connecting to Wi-Fi for 1-2 Sec |
| Operating Temperature | 14°F to 158°F (-10°C to 70°C) |
