Amuse Tech Solutions Water Detector Leakage Sensor
Amuse Tech Solutions water detector leakage sensor is an advanced solution designed to detect water leaks promptly.
Description
Overview
Amuse Tech Solutions water detector leakage sensor is an advanced solution designed to detect water leaks promptly. This sensor offers real-time monitoring, alerting users to potential water damage. With its high sensitivity and quick response, it ensures timely action to prevent water-related disasters in various environments.
Features
- At the same time Output carbon dioxide, formaldehyde, TVOC, PM 2.5, PM 10, temperature, humidity, a total of seven sets of data
- High sensitivity, stable data
- UART Or RS 485 output mode, can connect multiple sensors at the same time
- Temperature accurate to 32.18 °F (0.1 ℃), humidity accurate to 0.1%
- Automatically output seven sets of sensors monitoring data through RS 485/UART signal every 2 seconds
Technical Specifications
| Parameter | Measurement resolution | Range of measurement | Accuracy |
| C02 | 1 PPM | 400 PPM to 5000 PPM | ±3% + 50 PPM or ±10% |
| CH20 | 1 μg/m3 | 0 ug to 2000 ug/m³ | ±10% |
| TVOC | 1 μg/m3 | 0 ug to 2000 ug/m³ | ±25% |
| PM2.5 | 1 μg/m3 | 0 ug/m3 to 999 ug/m³ | ±10% or ±10 |
| PM10 | 1 μg/m3 | 0 ug/m3 to 1000 ug/m³ | ±10% or ±10 |
| Temperature | 32.18 °F (0.1 ℃) | -40 °F to 212 °F (0 °C to 50 °C) | 33.8 °F (±1 °C) |
| Humidity | 0.4% | 0% to 100% | ±3% RH |
| Physical interface | XH 2.54 | ||
| output | RS 485 Or UART, As your Request | ||
| Source Voltage | 5.0 V ± 0.2 V DC | ||
| Current | ≤500 mA | ||
| Warm-up time | 2 min (TVOC needs to be warmed up) | ||
| Operating Temperature | 32 °F to 122 °F (0 °C to 50 °C) | ||
| Operating humidity (non-condensing) | ≤95％ RH | ||
| Physical Size | 2.79 in × 2.4409 in × 0.69 in (71 mm x 62 mm x 16 mm) | ||
