Amuse Tech Solutions VFL Cable Tester
Amuse Tech Solutions VFL cable tester provides 5.6 in (14.24 cm) capacitive full touch screen and integrates automatic OTDR, expert OTDR, event map, OPM, VFL, LS and other functions.
Description
Overview
Amuse Tech Solutions VFL cable tester provides 5.6 in (14.24 cm) capacitive full touch screen and integrates automatic OTDR, expert OTDR, event map, OPM, VFL, LS and other functions. This product supports a dynamic range of 32 dB or 30 dB and can achieve accurate testing up to 62.14 mi (100 km). It achieves a minimum event dead zone of 4.9 ft (3 m) and a maximum sampling resolution of 0.98 in (2.5 cm). It provides 4600 mAh high density and large capacity polymer lithium battery, intelligent power saving management as well as power supply or charging by a power bank. This product measures length, loss, connection quality and other parameters of all kinds of optical fiber and cable. It supports engineering construction, line maintenance and emergency rescue test of FTTH, MAN and secondary backbone network communication system, as well as the development and production measurement of optical fiber and cable.
Â
Technical Specification
| Network | 5 G |
| Max. Dynamic Range | 32 dB or 30 dB |
| Optical Output Port | FC or UPC (standard, SC or UPC is optional) |
| Working Wavelength | 1310 or 1550 ± 20 nm |
| Event Dead Zone | 4.9 ft (3 m) |
| Sampling Resolution | 0.98 in (2.5 cm) |
| Density | 4600Â mAh |
| Display | 5.6 in (14.24 cm) Full touch screen |
| Dimension | 6.97 in x 4.3 in x 1.5 in (177 mm x 109 mm x 37 mm) |
| Weight | 1.8 lb (800 g) |
