Amuse Tech Solutions -Variety Stable Performance Circular Polarization Long Range UHF RFID Reader Access Control Systems– With The Frequency From 865 MHz To 928 MHz
Amuse Tech Solutions UHF RFID reader is suitable for RFID passive all-in-one reader and writer systems in the 902 to 928 MHz frequency band.
Description
Overview
Amuse Tech Solutions UHF RFID reader is suitable for RFID passive all-in-one reader and writer systems in the 902 to 928 MHz frequency band. Physical advantages: small size, beautiful appearance, protection level can reach IP67. Electrical performance advantages: high gain, low standing wave, low axis ratio, high bandwidth, excellent tag reading performance can be achieved within the operating bandwidth.
Technical Specifications
| Frequency | 865 MHz to 868 MHz (EU standard) or 902 MHz to 928 MHz (US standard) |
| Protocol | ISO or IEC18000-6C or IEC18000-6B or EPC C1Gen2 |
| Built-in Antenna | 9 dBi Circular antenna |
| Work Mode | Active or trigger or answer or password or mask mode, |
| Tag Recognition Speed | ≥ 300 pictures per s |
| Communication Interface | 1 x RS-232, 1 x RJ45, 3 x USB2.0 Type A, supports 4G full network or GNSS positioning or Bluetooth or WIFI multiple wireless communication networks. |
| GPIO | 2 relay outputs, 2 optocoupler isolated inputs each or 4 normal input IOs, GPIO x 5 |
| Operation System | Including but not limited to Windows, Android, IOS, Kirin, Tongxin, Hongmeng |
| RF Power | 0 dBm to 33 dBm |
| RSSI Detection | Support |
| Material | ABS Aluminum Alloy |
| Power Supply | DC 9 V to 24 V |
| IP Grade | IP67 |
| Read Distance | 26.25 ft to 39.37 ft (8 m to 12 m) (depends on tag) |
| Operation Temp | -4 °F to 158 °F (-20 °C to +70 °C) |
| Storage Temp | -22 °F to 176 °F (-30 °C to +80 °C) |
| Reader Size | 8.58 in x 8.58 in x 2.56 in (218 mm x 218 mm x 65 mm) |
| Net Weight | 2.65 lb (1.2 kg) |
