Amuse Tech Solutions UHF RFID 902-928Mhz Antennas 9dbi Circular Polarization SMA Connector Type N-50kfd Low VSWR Long Range Directional- Circular Polarization
UHF RFID 902-928Mhz Antennas with ISO18000-6B and EPC Class1 GEN2 standards, ideal for outdoor use, stable long-range detection and fast recognition.
Description
Features
- Support ISO18000-6B and EPC Class1 GEN2 international standards
- Integrated structure design, beautiful appearance
- Suitable for outdoor environment
- Integrate high-performance linear polarized antennas
- Recognize the long range distance stably
- Supports tag echo signal detection, tag data filtering, clock stamping, and input and output functions
- Recognition speed is fast, and the identification of single label can reach 140 times per second
Technical Specifications
|
Working frequency |
865 MHz to 868 MHz (EU standard) and 902 MHz to 928 MHz (US standard) |
|
Supported protocols |
ISO18000-6B and ISO18000-6C (EPCGEN2) |
|
Operation mode |
Fixed Frequency or Software Programmable |
|
Polarization mode |
Circular polarization |
|
Lobe width |
Horizontal 60 ° |
|
RF power |
RF power 0 dBm to 30 dBm and Software Programmable |
|
Connector |
SMA or N or Customized |
|
Gain |
4 dBi and 5.5 dBi and 8 dBi and 9 dBi |
|
Radome material |
ABS |
|
VSWR |
1.4 |
|
Reading speed |
Single card average reading is 64 bits and less than 15 ms |
|
Work mode |
Reading Active and reading passive and software programmable |
|
Communication Ports |
N Wiegand26 or 34 or 98 RS485RS232USB |
|
Input interface |
1 way trigger input |
|
Reading range |
0 ft to 26.25 ft (0 m to 8 m) (High power 0 ft to 49.21 ft (0 m to 15 m)) |
|
Status indicators |
Buzzer |
|
Antenna |
9 dbi circular antenna |
|
Power supply |
DC + 9 V |
|
Operation Temperature |
– 4 °F to 158 °F (- 20 ℃ to + 70 ℃) |
|
Size |
|
|
Weight |
3.86 lb (1.75 kg) |
