Amuse Tech Solutions UHF RFID 860-960Mhz Antennas Circular Polarization Long Range Wireless Mat-Integrated with TNC Port
Amuse Tech Solutions UHF RFID 860-960Mhz Antennas circular polarization long range wireless mat is a high end long range RFID UHF antenna.
Description
Overview
Amuse Tech Solutions UHF RFID 860-960Mhz Antennas circular polarization long range wireless mat is a high end long range RFID UHF antenna, its design carries the company’s research and development of ultra high frequency reader module and 12 dBi circular polarization antenna, the main control chip uses a new generation of high performance processor, with multi device communication, watchdog, heartbeat packet and real time monitoring equipment status information.
Features
- Integrated with TNC port
- Can connect to work with 4 port ,8 port or 16 port UHF reader
- Uses ABS and PC shell design
- Waterproof and dust proof
- Strong anti interference ability and lightning protection circuit design
- Compactness, portability and multi-interface
- Long recognition distance, high speed and high accuracy
- Strong anti-interference ability and good protection performance
- Easy installation and use
Technical Specifications
| Working Frequency | 860 MHz to 960 MHz |
| Tag Protocol | EPCglobal UHF Class 1 Gen 2 / ISO 18000-6C |
| Working Voltage | DC + 12 V |
| Reading Distance | ≥ 49.21 ft (≥ 15 m) |
| Multi-tags Reading | ≥ 200 tags per s |
| Antenna Type | 12 dbi linear polarization antenna |
| Read Range | 3.28 ft to 65.61 ft (1 m to 20 m) (Depend on The Tags and Reader) |
| Gain | 12 dBi |
| Data Transmission Mode | 860 MHz to 960 MHz |
| Working Humidity | ≤ 95 % |
| Communication Port | TNC port |
| Buzzer | Yes |
| Enclosure | ABS industrial plastic case |
| IP Grade | IP67 |
| Working Temperature | – 13 °F to 149 °F (- 25 °C to + 65 °C) |
| Storage Temperature | – 40 °F to 176 °F (- 40 °C to + 80 °C) |
| Dimension | 17.52 in x 17.52 in x 1.57 in (445 mm x 445 mm x 40 mm) |
