Amuse Tech Solutions Software Support Rssi Function With WiFi Rfid Card Reader Uhf Rfid Lot For Tool Management
Explore our versatile UHF RFID reader featuring Impinj R2000 chip, ISO 18000-6B/6C protocol, and customizable frequency bands.
Description
Overview
Explore our versatile UHF RFID reader featuring Impinj R2000 chip, ISO 18000-6B/6C protocol, and customizable frequency bands.
Technical Specifications
| Identification | UHF |
| Protocol | ISO 18000-6B/6C, EPC C1G2, GB/T29768-2013 |
| Chip | Impinj R2000 |
| Frequency Band(Optional) | Please tell our sales which band do you want before ordering: ETSI: 865 MHz to 868 MHz; JP: 916.8 MHz to 920.4 MHz; TW: 922.25 MHz to 927.75 MHz; ID: 923.125 MHz to 925.125 MHz; RUS: 866.6 MHz to 867.4 MHz; TEST: 802.75 MHz to 998.75 MHz; JP_LBT: 916.8 MHz to 920.8 MHz |
| Reading Speed | >600 pcs per s |
| Distance | About 49.2 ft (15 m) (Built-in antenna) |
| Function | Read & write function, Multiple label identification, Label data filtering, RSSI sensing signal strength |
| Hardware Info | |
| System Support | Android |
| Hardware | 1G SRAM, 8G ROM |
| Display Port | HDMI 1080P |
| Communication | RJ45, RS232, WiFi, 4G, BT |
| RF Port | 1/2/4/8CH TNC, (16 CH SMA) |
| Specifications | |
| Material | Aluminum |
| Installation Method | Fixed by screw holes |
| Power Supply | DC 5 V to 12 V |
| Environment | |
| Working Temperature | -4 ºF to 158 ºF (-20 ºC to 70 ºC) |
| Working Humidity | 10 % RH to 90 % RH |
| Size | 7.68 in x 6.06 in x 1.06 in (19.5 cm x 15.4 cm x 2.7 cm) |
