Amuse Tech Solutions High – Performance Portals UHF RFID Gate Reader With Auto Direction Detection Multi – Label Recognition
Long-range RFID reader with operating temperature range -4 °F to 140 °F (-20 °C to 60 °C), storage temperature -22 °F to 158 °F (-30°C to 70°C), adjustable output power, supports ceiling and wall mount installation.
Description
Technical Specifications
| Frequency Range | 902MHz to 928MHz |
| Protocol | ISO 18000-6C |
| Output Power | 8 dbm to 33dbm (adjustable) |
| Communication Interface | RS-232(DB9), RJ45 |
| Power Dissipation | About 45W |
| Power Supply | AC 220V±10% 47 to 63 Hz |
| Size | 17.32 in × 8.27 in × 1.57 in (440mm×210mm×40 mm) without support |
| Weight | approximately 16.53 lb (7.5 kg) without support |
| Installation Mode | Supports ceiling, ceiling and wall mount |
| Materials | Aluminium plus ABS |
| Operating Temperature | -4 °F to 140 °F (-20 °C to 60 °C) |
| Storage Temperature | -22 °F to 158 °F (-30°C to 70°C) |
| Humidness | 10 % to 95% RH no condensation |
| Installation Height | 9.84 ft to 16.40 ft (3 m to 5m) |
