Z Wave Plus Dimmer Controller for Intelligent LED Lighting – Amuse Tech Solutions
Amuse Tech Solutions’s Z-Wave plus dimmer controller for intelligent LED lighting is a switch multilevel device based on Z-wave Plus and its easy configuration, operation and can make the traditional LED dimmable lighting to be intelligent control.
Description
Overview
Amuse Tech Solutions’s Z-Wave plus dimmer controller for intelligent LED lighting is a switch multilevel device based on Z-wave Plus and its easy configuration, operation and can make the traditional LED dimmable lighting to be intelligent control. This Dimmer integrated Z-Wave communication module to connect with Z-Wave gateway. This device can be included and operated in any Z-Wave network with other Z-Wave certified devices from other manufacturers. All non-battery-operated nodes within the network will act as repeaters regardless of vendor to increase reliability of the network.
This device is a security enable Z-Wave Plus product (S0, S2) that can use encrypted Z-Wave Plus messages to communicate to other security enable Z-Wave Plus products. So, a security enabled controller is needed for take full advantage of all functionally. It also supports the Over the Air (OTA) feature for the product’s firmware upgrade. If you want your dimmer controller to be a security device that use secure/encrypted message to communicate in a Z-Wave network, then a security enabled Z-Wave controller is needed.
Features
- Smart Phone APP Control
- Adjust to the Brightness You Want
- High Load Type Compatibility and Dimmability
- Smart Dimmers with Multiple WAP Protocols
- Place It Wherever You Like
- Smart Voice and Remote Control
Technical Specifications
| Type | LED Dimmer |
| Function | Mobile Remote Control |
| Max. Load Power | 250 W |
| Connection Mode | No Neutral Required |
| Rated Input Voltage | 220 V to 240 V AC, |
| Power Range | 5 W to 250 W at 220V to 240 V LED 5 W to 250 W at 220 V to 240 V INC, HAL |
| Type Of Load | LED Retrofit or Incandescent-halogen |
| Controls | Push Rotary |
| Ambient Temperature (Ta) | 95 °F (35 °C) |
| Control Mode | One Way or Multi way |
| Protocol | Z-Wave Plus 500 |
| Application | Smart Home |
| Features | Flicker Free Lighting |
| Control Way | Phone App |
| Compatible Software | HOMEY, WINK |
| Operating Temperature | – 4 °F to 104 °F (-20 ℃ to 40 ℃) |
| Single Gross Weight | 1.9 oz (56.6 g) |
| Single Package Size | 1.7 in x 1.7 in x 1.5 in (45 mm x 45 mm x 40.45 mm) |
