Universal ZigBee Gateway with-300 Device Support & USB-C – Amuse Tech Solutions
Universal ZigBee Gateway supports 300 devices with USB-C or PoE power, dual modes, and advanced open-source firmware for seamless wireless connectivity.
Description
Technical Specifications
| Power Supply | USB-C Type or PoE 802.3af |
| Supported Connectivity | ZigBee over LAN, USB, and Wi-Fi |
| Main Chips | ESP32, LAN8720, CH340C |
| ZigBee Chip | CC2652P7 with +20 dB amplifier (used from hardware version v0.2 onwards) |
| Device Capacity | Supports up to 300 ZigBee devices |
| Operating Modes | Coordinator or router |
| LED Indicators | Blue: power, Red: USB or LAN Mode, Yellow: Z2M connection |
| Mode Switching | Button press: switch between USB or LAN mode; hold (2to4 sec): control LEDs ON or OFF; Hold (4to8 sec): activate flashing mode; Hold (10+ sec): reset on power |
| Firmware Updates | Update over LAN, Internet, or USB |
| Security | Authentication enabled |
| Firmware Type | Open source |
| Dimensions | 2.87 in x 2.83 in x 1.06 in (73 mm X 72 mm X 27 mm) |
