Universal Multi Protocol IoT Hub with Quad Core Processor – Amuse Tech Solutions
Multi-Protocol IoT Hub features BT 4.2 or 5.0 for seamless device pairing and includes USB 2.0 for wired device connections with Mounting Options.
Description
Features
- Flexible connection to various IOT terminals
- Usage Scenario
- Multiple Protocol Supported
- Extra Highlights
Technical Specifications
| Processor Manufacture | ROCKCHIP |
| Processor Main Frequency | 1.3 GHz |
| CPU | Wi-Fi: RK3326 Quad core, PX30 Quad core or MT8168 Quad core 3G: MT8321 Quad core (optional) 4G: MT8765 Quad core, MT8766 Quad core or MT8788 Octa core (optional) |
| Ram | 1GB, 2GB |
| Storage | 8GB, 16GB or 32GB |
| Wi-Fi Or BT | 802.11 ac bgn, BT4.2 or 5.0; 802.11 bgn |
| Wired Protocol | USB 2.0 |
| Connectivity | Zigbee, Z-wave, LTE Cat1 |
| Physical Press Key | Key 1 for software upgrade, Key 2 for reset |
| Mount Way | Back plate |
| Without | Display, Battery, Camera |
| Indicator | 2 x LED |
| Port | Micro SIM card push, Type C, DC in, Antenna SMA connections |
| GPU | Mali-T720 MP1 or Mali-400 MP2 (optional) |
| Network | Wi-Fi, GSM, 4g, 3G |
| Charging Interface | USB Type C |
| Private Mold | Yes |
| Weight | 8.39 oz (0.238 kg) |
