Ultrasonic Water Meter With High Accuracy And Long Life – Amuse Tech Solutions
Amuse Tech Solutions’s Ultrasonic Water Meter with High Accuracy and Long Life is an intelligent flow meter designed to measure water flow accurately.
Description
Overview
Amuse Tech Solutions’s Ultrasonic Water Meter with High Accuracy and Long Life is an intelligent flow meter designed to measure water flow accurately. This device features a sleek design, easy installation, high measurement precision, stable operation, strong anti-pollution and anti-corrosion properties, long service life, and minimal pressure loss. It is suitable for applications such as domestic water usage and central air conditioning system water flow metering.
Features
- Low starting flow rate
- Wide measuring range
- High measurement accuracy
- Stable operation
- No internal moving parts
- Open flow components
- Unaffected by impurities in water
- Long service life
- Good communication
Technical Specifications
| Type | Ultrasonic meter |
| Protection Class | IP68 |
| Nominal Diameter | 15, 20, 25, 32, 40, 50, 65, 80, 100 mm |
| Maximum Flow (Q4) | 3.1 to 125 m³/h |
| Common Flow (Q3) | 2.5 to 100 m³/h |
| Boundary Flow (Q2) | 0.02 to 0.8 m³/h |
| Minimum Flow (Q1) | 0.012 to 0.5 m³/h |
| Maximum Flow Reading | XXXXXXX.X m³ |
| Accuracy Class | 2 |
| Pressure Loss | ≤ 0.063 MPa |
| Maximum Working Pressure (MWP) | 1.6 MPa |
| Temperature Rating | T30 (86 °F) / T50 (122 °F) |
| Temperature Resolution | 0.01 °C |
| Environment Type | B Class (Indoor) |
| Power Supply | 3.6 V |
| Protection Grade | IP65 |
