UHF RFID Fixed Integrated Android Reader with Long Range Reading Capability – Amuse Tech Solutions
RFID Fixed Integrated Android Reader offers adjustable antenna power, and range of 82 ft. Ideal for various applications with customizable interfaces and robust build.
Description
Technical Specifications
| Standard | Â ISO18000-6B/ISO18000-6C/EPC Class1G2 |
| Working Frequency | Â 902 MHz to 928 MHz or 865 MHz to 868 MHZ |
| Interface | Â Wiegand263442, RS485, RS232 (TCP/IP, WIFI and GPRS is customizable) |
| Power Supply | Â DC-7.5 to 12 V, 3 A |
| Development Kit | Â Provide SDK development kit, and C#, C++, Java routines |
| Antenna Power | Â 1 W (adjustable by software) |
| Input/Output Interface | Â 1 way trigger input or 2-way relay output (customized) |
| Ani-Thunder | Â 6000 V |
| Antenna | Â 12 dBi polarization |
| Reading Range | 65.61 ft to 82 ft (20 m to 25 m) |
| Operating Temperature |  -49 °F to 149 °F (-45 ℃ to 65 ℃) |
| Size | Â 17.71 in x 17,71 in x 1.96 in (450 mm x 450 mm x 50 mm) |
| Weight | Â 11 lb (5 kg) |
