Transmission Assembles Vibration Resistance Optical Fiber for Industries – Amuse Tech Solutions
High-performance sensor with anti-ambient light protection, rapid response, durable housing, and precise detection accuracy. Ideal for various applications.
Description
Technical Specifications
| Output | NPN or PNP (NC or NO) |
| Supply voltage | 12 V DC to 24 V DC ± 10 %, ripple (P to P): ≤ 10 % |
| Anti ambient light | Incandescent: ≤ 20,000 lux, daylight: ≤ 30,000 lux |
| Housing material | PC+ABS |
| Output method | PNP or NPN |
| Current consumption | PNP: 900 mW or 900 mW, NPN: 950 mW or 850 mW |
| Material | Polycarbonate |
| Response time | 25 µs, 50 µs, 100 µs, 300 µs |
| Vibration resistance | Amplitude: 0.02 in (5 cm), frequency: 10 to 50 Hz |
| Detection accuracy | > 0.04 in (0.1cm) (fiber-related) |
| Shock proof | 500 m/s² (50G) 3 times each for X, Y, Z direction |
| Light source | 660 nm visible red light |
| High pressure resistant | 1000 V / AC 50 / 60 Hz 60 s |
| Protection circuit | Surge, reverse polarity, overload protection |
| Connection | 2 m PVC cable |
| Ambient illumination | Incandescent light: max 20,000 lux, daylight lamp: max 30,000 lux |
| Ambient temperature | 14 °F to 131 °F (-10 °C to 55 °C) (no icing) |
| Cable | 0.08 in (0.2 cm) |
| Size | 1.2 in × 0.4 in × 2.9 in (3.3 cm x 1.1 cm x 7.5 cm) |
| Weight | 3.17 oz (90 g) |
