Speed Master: Customizable High-Speed RPM Controller with OLED Display- Amuse Tech Solutions
High speed torque sensor with OLED display, offering precise measurements from 0-1000Nm capacity.
Description
Features
- Durable alloy, steel, or stainless-steel construction
- High-speed RPM measurement capability
- Embedded OLED screen for real-time data display
- Customizable cable length options
- User-friendly design for ease of installation
- Reliable ±1% F.S. output accuracy
Technical Specifications
| Insulation Resistance: | ≥5000 MΩ/ 100 VDC |
| Zere Output | ±1 % F.S. |
| Nonlinearity | ±0.1, 0.3 % F.S. |
| Hysteresis | ≤ ±0.05 % F.S. |
| Repeatability | ≤ ±0.05 % F.S |
| Creep | ≤ ±0.03 % F.S / 30 min |
| Material | Â Alloy, steel, stainless steel |
| Sensitivity | 1.5±10 % mV / V |
| Response Frequency | 100 μS |
| Excitation Voltage | (9 to 15 VDC) |
| Safe Overload | 150 % F.S. |
| Overload | 200 % F.S. |
| Input Resistance | 350, 750 ± 10 Ω |
| Output Resistance | 350, 750 ± 10 Ω |
| Temp Effect On Zero Balance | 0.03 % F.S. / 50 °F (10 ℃) |
| Temp Effect On Sensitivity | 0.03 % F.S. / 50 °F (10 ℃) |
| Cable Size | 17.06 × 9.84 ft (5.2 × 3 m) |
| Temperature Compensation Range | 14 °F to 140 °F (-10 ℃ to 60 ℃) |
| Use temperature Range | -4 °F to 149 °F (-20 ℃ to 65 ℃) |
