Solar Powered NB IoT Tracker with MQTT for Outdoor Monitoring – Amuse Tech Solutions
This device features NB-IoT location tracking, supports MQTT and HTTP protocols, and includes Nano and eSIM support. It offers Bluetooth connectivity.
Description
Features
- NB-IoT location tracking
- Supports MQTT and HTTP protocols
- Nano and eSIM support
- Bluetooth 5.0 connectivity enabled
- 3W solar panel integration
Technical Specifications
| Function | IoT System |
| Bluetooth Protocol | Bluetooth 5.0 |
| LTE M | B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B25/B26/B27/B28/B66/B85 |
| NB IoT | B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B25/B28/B66/B71/B85 |
| Wi Fi | Optional, 2.4GHz, positioning only |
| SIM Card | Nano and eSIM |
| Beacon Access Quantity | 100 beacon messages can be received within 1s, Maximum of 15 beacon messages at one LoRa communication |
| Certification | CE, FCC, RCM, BQB |
| Dimension | 6.30 in × 6.30 in × 2.17 in (160 mm x 160 mm x 55 mm) |
| Operating Temperature | -40 °F to 185 °F ( -40 ℃ to +85 ℃ ) |
| Weight | 5.29 oz (150 g) |
| Peak Current | Max. 140mA in transmit mode |
| Ingress Protection | IP66 |
| Positioning Precision | 3 metres |
| Encryption | AES128, X509 |
| Battery | Li-SoCl2 19000mAhx2, Optional: 19000mAhx4/19000mAhx6 |
| Bluetooth Positioning | Approx. 150,000 times ** |
| Standby Current | 25 μA |
| Max Current | 300 mA |
| Solar Panel | 3 W |
| Max Charging Current | 500 mA |
| Charging Rate | Max. 1500 mAh each day |
| Battery Life | 1 month @ 10s Bluetooth receiving duration and 60 report interval |
| Certification | CE, FCC, RCM |
