Solar Powered LoRaWAN Gateway with IP66 Protection – Amuse Tech Solutions
Solar-powered LoRaWAN gateway with Bluetooth 5.0, IP66 protection, and 2552-day standby time, ideal for asset tracking in outdoor IoT systems.
Description
Features
- Positioning and navigation system
- BLE module
- LoRaWAN connectivity
Technical Specifications
| Chipset | SX1276 |
| Bluetooth Protocol | Bluetooth 5.0 |
| LoRaWAN Protocol | LoRaWAN 1.0.2 B |
| LoRaWAN Band | US 915 MHz, AU 915 MHz, EU 868 MHz, EU 433 MHz, AS 920 MHz to 923 MHz, AS 923 MHz to 925 MHz, RU 864 MHz ID 920 MHz, KR 920 MHz, IN 865 MHz, KZ 865 MHz, CLAA, CN 470 MHz |
| LoRa Maximum RF Power | 20 dBm |
| LoRa Sensitivity | – 139dBm at SF12, BW 125 kHz, 434 MHz or 470 MHz – 137 dBm at SF12, BW 125 kHz, 868 MHz, 915 MHz |
| Access Quantity | > 500 in one LoRa gateway |
| Data Rate (Bps) | 300 to 30 K |
| Beacon Access Quantity | 100 beacon messages can be Received within 1 s, maximum of 15 beacon Messages at one single LoRa Communication |
| Peak Current | Max. 140 mA in transmit mode |
| Ingress Protection | IP66 |
| Positioning Precision | 9.8 ft (3 m) |
| Encryption | AES128, X509 |
| Standby Time | 2552 days Bluetooth receiving windows: 3 seconds Positioning interval: 5 min (300 s) Average data size: around 12 beacons (5.5 bytes per beacon, 800 ms beacon advertise interval) Use commands to change the period of position report to save power |
| Battery | Li-ion rechargeable battery 5.300 mAh |
| Battery Life | Adjustable Position Report Interval: 5 s x n (1 to 65536) heartbeat report interval: 30s x n (1 to 65536) Switch: mechanical customized data filter and data report: Support FOTA over Bluetooth: Support Max. beacons supported: 105, maximum of 15 beacon messages at one single LoRa communication at SF9 |
| Solar Panel | 3 W |
| Operating Temperature | – 40 °F to 185 °F (- 40 °C to 85 °C) |
| Weight | 5.3 oz (150 g) |
| Size | 6.3 in x 6.3 in x 2.2 in (160 mm x 160 mm x 55 mm) |
