Smart Gateway Zigbee Hub with 2.4GHz ZigBee RS485 Transceiver – Amuse Tech Solutions
ZigBee wireless transceiver module with RS485 interface with 20dBm power, and CC2530 chipset for smart city and industrial IoT applications.
Description
Technical Specifications
| Color | Black |
| Frequency Band | 2.405 GHz to 2.480GHz |
| Operating Voltage | 8 V to 28 V (DC) |
| Power | 20dBm |
| RF-Interface | SMA-K |
| Interface | RS485 |
| Function | 2.4 GHz Zigbee RS232 RS485 Transceiver |
| Keywords | CC2530 Zigbee Module |
| Interface | RS485 |
| Chipset | CC2530 |
| Operation Range | 0.80 miles (1.3 km) |
| Application | Home automation, Industrial IOT, Smart city |
| Size | 2.677 inches x 2.598 inches x 0.827inches (68 mm x 66 mm x 21 mm) |
