Single Wavelength FTTH PON OTDR with Built in Filter and VFL – Amuse Tech Solutions
Compact FTTH PON OTDR with built-in filter and VFL. Features rapid troubleshooting, high accuracy, and long-distance testing capability.
Description
Technical Specifications
| OPM&VFL | Yes |
| Wavelength | 1625 nm (built-in filter) |
| Connector | SC/FC(PC/UPC/APC) |
| OPM Supported Wavelength | (850, 1300, 1310, 1490, 1550, 1625) nm |
| Test Dead Zone | Less than 9.8 ft (3 m) |
| Distance Resolution | 3.3 ft (1 m) |
| Dead Zone of Reflective Event | Less than 32.8 ft (10 m) |
| Dead Zone of Attenuation Event | Less than 98.4 ft (30 m) |
| Length | Can reach up to 12.4 miles (20 km) |
| Pulse Width | 10 ns to 500 ns |
| Distance Uncertainty | ± (2.6 ft ± 0.01% * Test distance ± Resolution) |
| Threshold of Loss | Greater than 0.3 dB |
| Resolution of Loss | 0.1 dB |
| Storage Ability | 100 items |
| Display | 2.8 in TFT color screen |
| Port | Mini USB |
| Battery | 3 x AA 1.5V rechargeable lithium battery |
| Working Time | Standby >15 Hours, Test >8 Hours |
| Operating Temperature | Storage: -4 °F to 140 °F (-20 °C to +60 °C) Working: 14 °F to 122°F (-10 °C to +50 °C) |
| Dimension | 7.0 in × 3.5 in × 1.4 in (17.8 cm × 8.8 cm × 3.6 cm) |
| Weight | About 15.9 oz (450 g) |
