Portable Power Quality and Energy Monitoring Analyzer – Amuse Tech Solutions
Discover Portable Power Quality Analyzer, offering precise energy monitoring, harmonic analysis, and remote access with multi-phase support.
Description
Features
- Easy to carry around
- Enables remote data transmission
- Monitors electrical energy usage
- Supports various power analyses
- Accurate current measurement
- Tracks voltage and current quality
- Monitors live electrical data
- Ideal for multiple applications
- Measures harmonics and power factor
- Supports remote access and monitoring
Technical Specifications
| Phase | Three Phase and Single Phase |
| Measuring Energy Range | 0GWh to 999.9GWh |
| Display Type | Analog and Digital |
| Accuracy Class | Class 0.5 |
| Type | Portable Power quality analyzer |
| Display | 3.5 inch TFT screen display |
| Sampling Rate | 8k samples per second |
| Harmonic | 51th simultaneously |
| Frequency | 45Hz to 65 Hz |
| Current Transformer | 333mV CT |
| Storage | 16GB Memory, USB disk export |
| Communication | Modbus TCP, RJ45 port |
| Optional Service | Ethernet/ WIFI/4G gateway, GPRS, Cloud service |
| Operating Temperature | -13°F to 131°F (-25℃ to +55℃) |
| Dimensions | Â 8.464 in x 5.118 in x 2.362 in (21.5 cm x 13 cm x 6 cm) |
| Weight | 29.982 oz (850 g) |
