PoE Ethernet Fiber Switch with 120W Power & VLAN Support – Amuse Tech Solutions
Compact 8-port PoE fiber switch with 120W power, VLAN support, and 250m ultra-long transmission for home and enterprise networks.
Description
Overview
Amuse Tech Solutions PoE Ethernet Fiber Switch with 120W Power & VLAN Support is a cost-effective, small-scale switch ideal for home and enterprise networks. It provides 8 x 100 m Poe ports, 2 x 100 m electrical ports, and 1 SFP optical port uplink. The switch supports ieee 8023 af and ieee8032 at Poe standards, providing up to 30 watts of power to various devices. It features a unique dial switch design for enhanced network security and extended transmission range.
Features
- Uses internationally renowned, reliable chips
- Offers 8 x Poe ports
- 2 x uplink ports
- Supports ieee8023 af / at Poe
- Max output 30 W
- Features 2 G backplane bandwidth for data exchange
- Supports one-click VLAN,
- Long-distance transmission
- Built-in power supply
- Provides max 120 W power
- Includes lightning, surge, short circuit protections
- Compact design, plug and play, easy maintenance
Technical Specifications
| Port | 8 10 / 100 base-t Poe ports, Two 10 / 100base-t uplink ports, 1 SFP optical port uplink |
| Switching Performance | Backplane bandwidth: 2.8 g, MAC address table: 2 K, Support store and forward |
| Standard Protocol | IEEE802.3IEEE802.3i 10 Base-T
IEEE802.3 u 100 Base-T IEEE802.3 x Flow Control IEEE802.1 q VLAN IEEE802.3 af PoE IEEE802.3 at PoE+ |
| Transmission Medium and Distance | Class V line: 3937.01 in (100 m) in normal modeUltra long-distance transmission mode:Â 9842.52 in (250 m) |
| Poe | Poe ports: 8, DC 48 V, single port MAXIMUM POWER 30 W, Power supply line pair: (1 / 2)+, (3 / 6)- |
| Power Supply | 100 V AC to 240 V AC (50 Hz / 60 Hz) input, Total power 120 W |
| Indicator Light | P: Power indicator, s: ultra long-distance transmission mode indicator, V: VLAN mode indicatorPOE: port 1 to 8 Poe indicator, link: port 1 to 10 electric port connection indicator |
| Use Environment | Operating temperature: -10 °C to 55 ℃ (14 °F to 131 ℉)Storage temperature: -40 °C to 70 ℃ (-40 °F to 158 ℉)
Operating humidity: 10% to 90% non-condensing Storage humidity: 5% to 90% non-condensing |
| Physical Characteristics | Size (W x D x H): 7.87 in x 4.72 in x 1.73 in (200 mm x 120 mm x 44 mm)Weight:Â 2.20 lb (1 kg) |
