Optical Time Domain with Automatic Test Mode – Amuse Tech Solutions
Compact handheld OTDR with automatic and manual test modes, versatile connectivity, high-precision results, and easy maintenance features.
Description
Features
- Automatic test mode
- Interchangeable optical connectors
- Built-in fault locator
- High-precision measurements
Â
Technical Specifications
| Fiber Type | Single-Mode, Multi-Mode, Single-Mode/Multi-Mode |
| Display | 5.8-inch LCD Screen With Touch Functionality |
| Maximum Dynamic Range | Up to 45 dB (Varies By Model) |
| Event Dead Zone | As Low as 3.28 ft (1 m) |
| Attenuation Dead Zone | Approximately 19.69 ft (6 m) |
| Test Range | Up to 158.4 mi (255 km) |
| Pulse Widths | Ranges From 5 ns to 20,000 ns |
| Distance Measurement Accuracy | ±(2.46 ft + Sampling Interval + 0.005% × Test Distance) |
| Loss Measurement Accuracy | ±0.05 dB/dB |
| Reflection Measurement Accuracy | ±3 dB |
| Data Storage Capacity | ≥2000 Test Results |
| Optical Port Type | FC/PC (Interchangeable with SC, ST) |
| Data Ports | USB, Mini-USB, Ethernet Port (10M/100M) |
| VFL Output Power | ≥5 mW |
| Light Source Output Power | ≥-5 dB |
| Optical Power Meter Range | +26 dBm to -50 dBm (Optional: +6 dBm to -70 dBm) |
| Relative Humidity | 0% to 95% (Non-Condensing) |
| Operating Temperature | 23°F to 122°F (-5°C to 50°C) |
| Storage Temperature | -4°F to 158°F (-20°C to 70°C) |
| Dimensions | 8.94 in × 6.30 in × 2.76 in (22.7 cm × 16 cm × 7 cm) |
| Weight | ≤2.43 lbs (1.1 kg) |
