Network Cable Tester with High Speed Ethernet – Amuse Tech Solutions
Network cable tester for detecting physical, link, and network layers, quickly locating faults and assessing link quality efficiently.
Description
Features
- High-Speed Ethernet
- Compact Design
- Long Battery Life
- Multiple Protocols Supported
Technical Specifications
| Ethernet Ports | RJ-45, 10/100/1000Mbps, self-adaptation |
| Cable | Cat3, Cat5, Cat5e, Cat6 UTP |
| Protocol | IP, ICMP, TCP, UDP, DHCP, DNS, HTTP, LLDP, CDP, NDP, etc. |
| Display | 2.2 in TFT LCD, 220×176 pixels |
| LED | 7 |
| Buttons | 9 |
| Storage | Micro-SD, 4G max |
| App Connector | USB 2.0 FS |
| Network Ports | 2 RJ-45 ports |
| PoE | IEEE802.3af, IEEE802.3at |
| Work Humidity | <=90% RH (no condensation) |
| Power Model | Mini USB port, 5 V, 1.5 A (Max.) |
| Battery | Li-Ion battery, 3.7 V, 2400 mAh |
| Charging Time | 2.5 hrs to 3 hrs |
| Working Time | 6 hrs to 10 hrs |
| Charging Environment | 32 ℉ to 95 ℉ (0 °C to 35 °C) |
| Work Environment | 32 ℉ to 140 ℉ (0 °C to 40 °C) |
| Storage Environment | -4 ℉ to 185 ℉ (-20 °C to + 85 °C) |
| Size | 5.35 in x 3.03 in x 1.25 in (13.6 cm x 7.7 cm x 3.2 cm) |
| Weight | 8.46 oz (240 g) (battery included) |
