Multiple Function Clinical Analyzer with Touch Screen – Amuse Tech Solutions
Transform your lab efficiency with our CE & ISO13485-certified analyzer, featuring 300 test programs, touch screen, and coagulation function.
Description
Features
- Touch screen LCD display
- Coagulation and incubator function
- Different size of holes
- Long time warranty
- Branded spare parts
- Multiple programs and sample results
- Triple mode flow cell, cuvette and coagulation
- 5 USB ports & 1 Ether net port
Technical Specifications
| Certification | CE, ISO13485 |
| Group | All |
| Interface | 4 USB Hosts, 1 USB Slave, 1 Ethernet Port. |
| Memory | 200000 Results Can Be Stored |
| Printer | Build in Thermal Printer, 2.24 in (5.7 cm) Printer Paper |
| Test Method | End Point, Kinetics, Fixed Time, 2 Point Kinetic |
| Display | 7.0″ TFT LCD with Touch Screen, 800 x 480 Pixels |
| Test | up to 300 Tests Can Be Programmed |
| Inbator Function | Yes |
| Coagulation Function | Yes |
| Optics | 7 standard filters: B40nm, 405nm, 450nm, 505nm, 546nm, 578nm, 630nm. 2 more for optional |
| Test Method | 1 point end, 2 point end(Sample blank), Kinetics, Fixed-time, Coagulation and incubation (optional). |
| Lamp House | Long life tungsten halogen lamp (6 V or 10 W); auto-sleep function |
| Flow Cell Capacity & Optical Path | 32 ul, 0.39 in (1 cm) |
| Resolution | 0.0001 Abs |
| Photometric Range | 0.0000 ABS to 4.0000 Abs |
| CPU | ARM Cortex-A8, 720M Hz |
| Memory | DDR2 SDRAM: 1G bit |
| Flash | 256 MB; Over 300 programs; 200000 results can be stored |
| Interface | 4 USB Hosts, 1 USB Slave, 1 Ethernet port. USB port (host) for keyboard, mouse, printer, U disk, barcode reader etc USB port (slave) for PC connection (support PC software control function) |
| Production Capacity | 1000units/Month |
| Power Requirement | Wide power supply AC 100 V to 240 V, 50 Hz or 60 Hz |
| Humidity | 30 % to 80 % |
| Operating Temperature | 50 ⁰F to 86 ⁰F (10 ⁰C to 30 ⁰C) |
| Temperature | 77 ⁰F, 86 ⁰F, 98.6 ⁰F (25 ⁰C, 30 ⁰C, 37 ⁰C) and Room temperature. By means of Peltier elements |
| Specification | 15.75 in x 11.81 in x 6.3 in (40 cm x 30 cm x 16 cm) |
