Multi Protocol Smart Gateway with 4100 MAh Battery Backup – Amuse Tech Solutions
Multi-Protocol Smart Gateway provides 5V or 2A output for connected devices, supports LTE FDD data rates up to 10 Mbps (DL) in a space-saving size.
Description
Features
- Multiple Protocol (wire and wireless supported)
- Battery Backup
- High Programmable
Technical Specifications
| Output | 5V or 2A |
| Power Adapter | 100V to 240V 50Hz or 60Hz |
| Power Supply | 4.5V to 5V DC |
| Current | 350 mA at 5V |
| Power Seat Aperture | 0.14 in (3.5 mm) |
| Needle Diameter | 0.05 in (1.35 mm) |
| Network Interface | WLAN or LAN port |
| Wireless Protocol | LTE Cat M1, Wi-Fi, Zigbee, Bluetooth, Z-wave |
| CPU | MTK7620A |
| System | Open Wrt |
| Access Devices | Up to 100 |
| LTE CAT M1 Operation Frequency Band | 850, 900, 1800 or 1900 MHZ |
| LTE CAT M1 Global | LTE: FDD: B1, B2, B3, B4, B5, B8, B12, B13, B18, B19, B20, B26 or B28 |
| LTE CAT M1 North America | LTE TDD: B2, B4, B12 or B13 |
| LTE CAT M1 LTE TDD | B39 (for cat.M1 only) |
| Li battery | 4100 mAH (It can last 4 hours without DC power) (optional) |
| LTE CAT1 LTE FDD | B2, B4, B5, B12 or B13 |
| LTE CAT1 WCDMA | B2, B4 or B5 |
| LTE CAT1 LTE FDD Data Rate | 10 (DL) or 5 (DL) |
| Indicator LEDS | 1) Power LED normally on when powered on. 2) Zigbee, BLE or Z-WAVE LED flash when the signal comes 3) Wi-Fi LED normally on after connecting to Wi-Fi for 1 to 2 seconds |
| Reset Button | The reset button is a hole button; after pressing the reset button for more than 5 seconds, the Gateway will be restored to the factory settings |
| Operating Temperature | 14°F to 158°F (-10°C to 70°C) |
| Working Temperature | 41°F to 140°F (5℃ to 60℃) |
