Description

Overview

Amuse Tech Solutions ZigBee Module is developed based on DSGW-210. It’s with multiple protocols and edge computing functions. It provides reliable connectivity for a wide range of wireless IoT devices. The gateway’s modular architecture provides the ability to customise many gateway features providing an off-the-shelf solution that meets your exact needs. Options include Cellular, Bluetooth, Wi-Fi, Ethernet, USB, ZigBee, Z-wave and Li battery backup. It can work with AWS IoT Core service.



Features

• Multi-Protocol Support Zigbee, BLE, Wi-Fi, Z-Wave, and AWS IoT
• Gateway & Edge Computing Local data processing before cloud transfer
• Raspberry Pi-Based Built on Raspberry Pi’s flexibility and scalability
• Security Ensures secure data transmission
• AWS Integration Seamlessly connects to AWS IoT
• Versatile Suitable for various IoT applications
• Developer-Friendly Benefits from Raspberry Pi’s community
• Remote Management Offers remote device monitoring



Technical Specifications

Power Supply	USB type-C 5 V /3 A
Reset button	The reset button is the hole button. After pressing the reset button for more than 5 seconds, the Locator will be restored to the factory settings.
Switch	On/Off power
Network Interface	WAN/LAN variable.
USB	USB 2.0
SIM card	Micro SIM card
Wireless protocol	ZigBee-WAVE,BLE,Wi-Fi
Antenna	ZigBee/BLE PCB Antenna; Z-WAVE/Wi-Fi FPV Antenna
Li battery	4100 mAh
Installation method	Flat,Ceiling,DIN
RTC	Real Time Clock operated from on board battery
Operating humidity	10% RH to 90% RH
IP rating	IP 22
Cooling	Heat dissipation silicone/aluminium
Current	500 mA & 5 V
Operating Temperature	14 °F to 140 °F (-10℃ to 60℃)
Storage Temperature	-40 °F to 185 °F (-40℃ to 85℃)
