Long Range Waterproof IoT Gateway with Wi-Fi GPS ZigBee LTE – Amuse Tech Solutions
: Industrial IoT Gateway offers long-range wireless connectivity with GPS, supporting multiple protocols including Wi-Fi, ZigBee, and LTE.
Description
Features
- Supports up to 100 devices
- Waterproof IP66 rating
- 128MB RAM for fast processing
- Works in extreme conditions: -4°F to 158°F
- Dual-band Wi-Fi and ZigBee
- WAN or LAN variable network interface
- Supports LTE CAT M1 and CAT1
- USB powered (12V or 2A)
Technical Specifications
| Category | Specifications |
| Working Temperature | -4°F to 158°F (-20°C to 70°C) |
| Power Supply | USB Port (12V or 2A) |
| Wireless Protocol | Wi-Fi, Z-Wave, BLE, ZigBee, LTE, PoE |
| CPU | MT7628 |
| System | OpenWrt |
| Access Devices | Up to 100 |
| Indicator LED | Three (Green, Yellow, Red) |
| RAM | Up to 128MB |
| Network Interface | Supports CAT-5 or CAT-5E for Data Transmission and PoE (44V to 57V), WAN or LAN Variable |
| Indicator LEDs | Power LED: on When Powered Network LED: on When Connected LED: On after Connecting to Wi-Fi (1 to 2 seconds) |
| LTE CAT M1 | Frequency Bands: 850 or 900 or 1800 or 1900MHzGlobal LTE FDD: B1 or B2 or B3 or B4 or B5 or B8 or B12 or B13 or B18 or B19 or B20 or B26 or B28LTE TDD: B39 (for cat. M1 only) |
| LTE Global | LTE FDD: B1 or B2 or B3 or B4 or B5 or B8 or B12 or B13 or B18 or B19 or B20 or B26 or B28 |
| LTE North America | LTE TDD: B2 or B4 or B12 or B13, LTE TDD: B39 (for CAT M1) |
| LTE CAT1 | LTE FDD: B2 or B4 or B5 or B12 or B13 WCDMA: B2 or B4 or B5 LTE FDD Data rate: 10Mbps (DL) or 5Mbps (UL) |
| LTE Data Rate | 10 (DL) or 5 (UL) Mbps |
| Antenna | Wi-Fi, LTE, Optional BT, ZigBee, GPS |
| Operating Temperature | -4°F to 158°F (-20°C to 70°C) |
| Current | 1000mA at 5V |
| IP Rating | IP66 |
