IP67 Waterproof Module Zigbee Replaceable Battery 1000 mAh Chipset nRF52 – Amuse Tech Solutions
Experience reliable connectivity with our IP67 waterproof Zigbee module featuring a replaceable 1000 mAh battery and nRF52 chipset.
Description
Overview
Amuse Tech Solutions ZigBee Module is a new generation beacon that is loaded with the Bluetooth 5.0 hardware platform and Mini Beacon Plus intelligence software. E9 has a smart rotatable mechanical design for the housing that makes the coin battery replaceable and IP67 waterproof grade combination perfectly. Moreover, E9 can be fixed by the screw and 3M adhesive. E9 Dear Beacon advertises standard iBeacon and Eddystone (UID, URL, TLM) data packet simultaneously. The user can configure the E9 Dear Beacon via configuration app Beacon SET+ as well.
Features
- IP67 waterproof
- Replaceable coin battery 1000mAh
- Advertising iBeacon & Eddystone
- Unique MAC address (ITU)
- Bluetooth 5.0 chipset nRF52 series
- 100 metres advertising distance
- Internal power ON/OFF push button
- Tough enclosure and screw fixing
Technical Specifications
| Case colour | Black |
| Battery Type | CR 2477, replaceable |
| Battery lifetime | 2 years |
| Transmission range | 100 m |
| Operation voltage | 1.8 V to 3.9 V |
| Transmission circuit | 5.3 mA |
| Waterproof grade | IP 67 |
| Antenna | 50 ohms |
| Accessories | Screws/Double adhesive |
| Broadcasting interval | 900 Ms |
| Size | 1.93 in x 2.60 in x 0.69 in (49 mm x 66 mm x 17.5 mm) |
