IOT Wideband Built in Preamplifier Acoustic Emission Sensor – Amuse Tech Solutions
Discover the IOT wideband built in preamplifier acoustic emission sensor with a high frequency range, 50 ohms preamp impedence and integral preamplifier
Description
Technical Specifications
| Frequency Rang | 100 KHz to 1000 KHz |
| Resonant Frequency | 500 KHz |
| Impedence | 50 ohms |
| Built In Preamp | 34 dB 12 V |
| Sensitive Peak | Ø 65 dB |
| Temperature | -4 °F to 122 °F (-20 to 50 ℃) |
| Dimensions | 0.86 in X 1.003 in (22 mm X 25.5 mm) |
| Case Material | SUS 304 |
| Face Material | Ceramic |
| Protectio Grade | IP62 |
| Connector Type | SMA |
