IoT Positioning Module with Bluetooth 5.0 and IP66 Water Level – Amuse Tech Solutions
High-precision IoT positioning module with Bluetooth 5.0, LoRaWAN 1.0.2B, IP66, 5300mAh battery, SX1276 chipset, CE or FCC certified, 3m accuracy
Description
Technical Specifications
| Chipset | Â Sx1276 |
| Type | BLE module |
| Function | IoT system |
| Bluetooth Protocol | Bluetooth 5.0 |
| LoRaWAN Protocol | LoRaWAN 1.0.2b |
| Certification | CE, FCC, RCM, BQB |
| Dimension | 6.3 inch x 6.3 inch x 2.2 inch (160 mm x 160 mm x 55mm) |
| Operating Temperature | -40°F to 185°F (-40℃ to +85℃) |
| Peak Current | Max. 140mA in transmit mode |
| Ingress Protection | IP66 |
| Positioning Precision | 3 metres |
| Battery | 5.300 mAh |
