High-Temperature Waterproof UHF RFID Tag for Industrial Line Tracking – Amuse Tech Solutions
PCB RFID tag supports ISO18000-6C, with a read range up to 19.6 ft and withstands extreme temperatures. Ideal for industrial line tracking in harsh environments.
Description
Overview
Waterproof RFID tags for industry application. Read up to 19.6 ft, with customizable logo and durable memory. Ideal for line tracking in extreme temp.
Features
- Support ISO18000-6C EPC Gen2
- Read distance up to 19.6 ft 19.6 ft (6 m)
- Withstand very high temperature
- Anti metal surface in anything harsh environment
Technical Specifications
| Frequency | 860 MHz to 960 MHz |
| Protocol | EPC Class1 Gen2 or ISO 18000-6C |
| Special Features | Waterproof |
| Chip | U8 or as want |
| Communication Interface | RFID |
| Application | Producing Line Tracking, Industry |
| Reading Distance | 3.2 ft to 19.6 ft (1 m to 6 m) |
| Material | PCB |
| Customized Support | Customized logo |
| Memory Size | EPC 96 bits, TID 64 bits; User Memory 512 bits |
| Read Or Write Cycles | 100,000 times |
| Tag Air Interfaces | EPC Class 1 Gen 2 |
| Working Temperature |  -22 °F to 536 °F (-30 °C to 280 °C) |
| Storage Temperature | -40 °F to 572 °F (-40 °C to 300 °C) |
| Dimensions | Â 1.5 in X 0.3 in X 0.1 in (40 mm X 10 mm X 3 mm) |
