Handheld Optical Time Domain Reflectometer Built in VFL – Amuse Tech Solutions
Portable optical fiber tester for accurate fault detection in fiber cables, perfect for efficient network maintenance and troubleshooting
Description
Features
- Rugged and lightweight
- Precise fault detection
- Built-in VFL tool
- Long-lasting battery
Technical Specifications
| Fiber Type | 9/125um SM Fiber |
| Dynamic Range | 22 dB |
| Pulse Width | 5 ns to 8000 ns, Auto |
| Event Dead Zone | 3 m (9.84 ft) |
| Attenuation Dead Zone | 10 m (32.81 ft) |
| OPM Power Range | -50 to +26 dBm |
| VFL Output Power | ≥10 mW |
| Battery Life | ≥2000 measurements |
| Data Storage | >500 records |
| Display | 2.6-inch screen |
| File Format | Saves in SOR format |
| Humidity | 0 to 85% (non-condensing) |
| Operating Temperature |  23 ℉ to 104 ℉ (-5 ℃ to 40 ℃) |
| Storage Temperature |  14 ℉ to 140 ℉ (-10 ℃ to 60 ℃) |
| Net Weight | 300 g (0.66 lbs) |
