GPRS 3 G 4 G IoT Module with Modbus Tophet RS485 RS232 Two-Way Data SMS Control – Amuse Tech Solutions
Advanced GPRS 3G 4G IoT module with Modbus, RS485, and RS232 supports two-way data communication and SMS control for versatile connectivity.
Description
Overview
Amuse Tech Solutions ZigBee Module It monitors the industrial system real-time running status and data, as well as constructs the remote device to a proprietary central computer and mobile phones through the GSM/GPRS/3G/4G/Wi-Fi/Ethernet communication network. It efficiently acquires the remote equipment operating parameters and process management, and can be widely used in industrial automatic control, base station / computer room monitoring, environmental monitoring, water conservancy projects, power industries, agriculture, etc.
Features
- Option network: GPRS, 3G, 4G
- TCP/IP connect at most 4 servers (support Static IP address or domain)
- Events (e.g., alarm, timer) trigger upload data
- Communication protocol: Modbus Tophet post, Cwt_IO(two-way communication
- Support two-way data transparent transmission with RS485 or RS232
- Editable alarm and recover SMS with time stamp
- Query any IO channel’s status or value via SMS command
- Control output via SMS command
- SMS report any IO channel’s status or value on schedule
- Remote setting via SMS commands
- Can query SIM card balance, SMS forward
Technical Specifications
| Wireless Network | GSM/GPRS (optional 3G, 4G) or Wi-Fi |
| Ethernet | 1 port RJ45, 10M/100M adaptive |
| Digital Input | 4 channels |
| Digital Output | 2 channels |
| Analog Input | 8 channels |
| Protocols | Modbus, HTTP Post, CATIO |
| Working Environment | -22 °F to +158 °F (-30 ℃ to +70 ℃) / 5% RH to 95% RH |
| Dimensions | 5.12 in x 3.15 in x 0.98 in (130 mm x 80 mm x 25 mm) |
