Gigabit Ethernet Switch for FTTH/FTTX with 680 Gbps Capacity & 4 GE Ports – Amuse Tech Solutions
Versatile gigabit Ethernet switch for FTTH/FTTX with 680 Gbps capacity, 4 GE ports, and 2 GPON ports. Offers 3-year warranty and reliable fiber-optic performance.
Description
Overview
Amuse Tech Solutions Gigabit Ethernet Switch for FTTH/FTTX with 680 Gbps Capacity & 4 GE Ports. They feature SFP slots for physical interfaces and include 4 GE and 2 GE (SFP) or 10 GE (SFP+) uplink options. The GPON ports deliver impressive speeds, with 1.244 Gbps upstream and 2.488 Gbps downstream capabilities. They utilize SC or UPC connectors and are powered by AC power, making them reliable and high-performance solutions for fiber-optic networks.
Technical Specifications
| Transmission Rate | 10 Mbps or 100 Mbps or 1000 Mbps |
| Switch Capacity | 680 Gbit/s |
| Memory (RAM) | 4 GB |
| Flash | 1 GB in total |
| PoE | Not supported |
| Rated voltage range | 100 V AC to 240 V AC, 50 Hz or 60 Hz-48 V DC to -60 V DC |
| Maximum voltage range | 90 V AC to 264 V AC, 47 Hz to 63 Hz-36 V DC to -72 V DC |
| Maximum power consumption (100% throughput, full speed of fans) | 74 W (without card) |
| Typical power consumption (30% of traffic load) | 58 W (without card) |
| Dimensions (H x W x D) | 1.75 in x 17.4 in x 16.72 in (44.4 mm x 44.0 mm x 42.7 mm) |
