This Fiber Optical Converter with Video is reliable high-speed transmission over fiber.
Description
Features
- Independent 1 U rack structure
- Supports one core optical transmission with 4 channels of bidirectional analog video and 4 channels of gigabit ethernet sharing and
- 2 channels telephone and 8 channels bidirectional contact closure and 1 channel of bidirectional RS485 data and 1 channel bidirectional
- No compression, real time signal transmission
- Advanced circuit design, full hardware scheme, to ensure the reliability, consistency and stability of equipment
- Power and other parameter status indicator to monitor system operating status
Technical Specifications
| Wavelength | 1310 nm to 1550 nm |
| Bit Rate | 1.5 Gbps |
| Sensitivity | > -24 db |
| Enthernet Channel | 4 Channel bidirectional video |
| Vide Bandwith | 6 Mhz |
| Maximun Switching | 2 a |
| Mechanical Durability | 100.000.000 times |
| Maximum Output Power | 60 W |
| Power Consumtion | < 30 W |
| Temperature | -4 °F to 167 °F (-20 °C to 75°C) |
| Size | 17.32 in x 7.87 in x 1.77 in (44.0 cm x 20.0 cm x 4.5 cm) |
| Weight | 3.17 lb (1.45 kg) |
