Ethernet Tester with 7 in Display & 4 GB Internal Memory – Amuse Tech Solutions
7” TFT-LCD OTDR with 12 hrs battery, 4 USB ports, 4 GB internal memory, and IP65 rating. Operates in -10°C to +50°C, with fast charging and multiple language options.
Description
Technical Specifications
| Display | 7 in (17.78 cm) TFT-LCD with LED backlight |
| Interface | 3 × USB port (USB 2.0, Type A USB×2, Type B USB×1) |
| Power Supply | 10 V (dc), 100 V (ac) to 240 V (ac), 50 Hz to 60 Hz |
| Battery | 7.4 V (DC) or 4.4 Ah lithium battery (with air traffic certification) Operating time: 12 hrs, Telcordia GR-196-CORE Charging time: <4 hrs (power off) |
| Power Saving | Backlight off: Disable, 1 minutes to 99 minutes Auto shutdown: Disable, 1 minutes to 99 minutes |
| Data Storage | Internal memory: 4 GB (about 40,000 groups of curves) |
| Language | User selectable (English, Simplified Chinese, traditional Chinese, French, Korean, Russian, Spanish and Portuguese contact us for availability of others) |
| Environmental Conditions | Operating temperature and humidity: 14 °F to 122 °F (-10 °C to +50 °C), ≤95% (non-condensation) Storage temperature and humidity: -4 °F to 167 °F (-20 °C to +75 °C), ≤95% (non-condensation) Proof: IP65 (IEC60529) |
| Dimension | 11.81 in x 10.63 in x 5.9 in (30 cm x 27 cm x 15 cm) |
| Weight | 3.96 lb (1.8 kg) |
