Ethernet and Fiber Tester with Multi Stream VLAN Support – Amuse Tech Solutions
Discover the Ethernet and fiber tester supporting VLAN stacking, multi-stream testing, and remote loopback for efficient network performance analysis.
Description
Features
- 10/100/1000Mbps electrical/optical port (dual optical and dual electrical)Â
- Excellent innovative ergonomic design, easy to carryÂ
- Equipped with a wrist strap and bracket for easy operation in various environmentsÂ
- 5-inch LCD color touch screen, intelligent navigation menuÂ
- Graphical and numerical display of test resultsÂ
- RFC2544 automatic testing for fast network testing and fault findingÂ
- Complete Y.1564 testingÂ
- LED indicator light, screen display characters and icons for operators to understand the current workÂ
- Equipped with a wrist strap and bracket for easy operation in various environmentsÂ
- Large capacity memory to store setting information and test resultsÂ
- Instrument embedded software can be easily upgraded
- L1/L2/L3/4BER testing
- Complete RFC2544 testing throughput, packet loss rate, latency, back-to-back
- Multi-business testing (10 streams)
- Support for receiving end traffic filtering statistics
- Support LAN testing
- Connectivity testing: PING, TRACE ROUTE, IP scanning
- Supports statistics such as frame length, frame type, and utilization in pass and terminal modes
- Optical power test, temperature, working current, and working voltage test of optical module
- Virtual cable testing (VCT: identifying cable short circuits, open circuits, and cable length information)
- Service interruption time test
- Provide testing functions such as port positioning, packet capture, and loopback
- Jitter test
- Upload test data to a PC through USB interface, and analyze, organize, archive, and print out measurement results on the PC
Technical Specifications
| Wavelength (nm) | 850, 1310, 1550 |
| Ports | 10/100/1000 Mbps, dual optical/electrical |
| Design | Ergonomic, portable, wrist strap, bracket |
| Display | 5-inch LCD touch screen |
| Testing | RFC2544, Y.1564 |
| Indicators | LED, icons, clear status display |
| Memory | Large capacity for settings and results |
| Upgrades | Embedded, easily upgradable software |
| Laser Type/Connector/Transceiver | VCSEL/LC/SFP FP/LC/SFP DFB/LC/SFP |
| Optical Interface | Two ports: 10/100BaseT half/full duplex, 1000BaseT full duplex |
| Connector | RJ-45 |
| Test Items | Y.1564, 100BaseT RJ-45, 1000BaseT RJ-45 |
| Test Mode | Remote loopback or dual testing device mode |
| Network Testing Standard | ITU-T Y.1564, RFC2544 |
| BERT Error Code Test | Supports layers 1 to 4, with/without VLANQ-inQ |
| Through Mode | Service provider network and customer equipment flow segmentation |
| Service Interruption Time (SDT) | Minimum, maximum, last intermediate, average, total, threshold time |
| Multi-Stream Generation | Supports up to 16 data streams on Ethernet and IP networks |
| VLAN Stacking | Supports up to 2 layers of VLANs (including IEEE802.1adQ-in-Q) |
| Test Interface | Dual RJ45 ports: 10/100/1000 BASE-T, Dual SFP port: 1000BASE-SXLXZX |
| Supported Standards | IEEE 802.3, RFC3393, RFC2544, Y1564 |
| Power Supply Method | Lithium battery, 1 power adapter |
| Operating Temperature | 32 °F to 122 °F (0 °C to 50 °C) |
| Dimension | 7.48 in x 5.12 in x 2.56 in (19 cm x 13 cm x 6.5 cm) |
| Weight | 28.21 oz (800 g) |
