Dual-Port 10G Ethernet Tester with 7-Inch Touchscreen & Protocol Support – Amuse Tech Solutions
Handheld Ethernet tester with dual-port 10G capability, 7-inch touchscreen, and full protocol support for advanced diagnostics.
Description
Overview
Dual-Port 10G Ethernet Tester with 7-Inch Touchscreen & Protocol Support is handheld dual-port 10G full protocol tester is widely used in any Ethernet-specific test, including service operator performance evaluation of Ethernet, Metro Ethernet or mobile backhaul installation, activation, or maintenance, point-to-point Ethernet Deployment of access services, and online fault diagnosis of real-time information flow, etc. Support a variety of communication protocols to meet different test requirements. Such as synchronous Ethernet, E1, SDH, OTN and other measurement functions.
Features
- Online help supports
- Recovery factory settings support
- Name file in Chinese support
- Screen shot function support
- Touch-screen soft keyboard input support
- Browser support timing shutdown and sleep support
- File format PDF, CSV
- Configure file Save personalized configure file, can import and export
Technical Specifications
| Display | 7 in (17.78 cm) 800 x 480 dot-matrix TFT touchscreen |
| Interface | USB 2.0 × 2; MicroSD x 1, up to 64 GB Storage Internal 8 GB Flash memory |
| External support | U disk storage |
| Battery | 7.4 V 5300 mAh Battery, 39.22 Wh Maximum 4 hrs operating time |
| Battery Life | Over 3 hrs |
| Battery charge time | 5 hrs to full charge |
| Supported rates | 10 BaseT, 100 BaseTX, 1000 Base-T, 1000 Base-FX |
| Supported standard | IEEE802.3, RFC 2544, Y.1564, IEEE1588v2 |
| Total power consumption | Less than 12 W |
| Relative humidity | 0% to 95% non-condensing |
| Dimensions (LxWxH) | 8.11 in x 6.73 in x 2.95 in (206 mm x 171 mm x 75 mm) |
