Driver Laser Zigbee High Light Environment Smooth Glass Realistic View – Amuse Tech Solutions
Driver Laser Zigbee designed for high light environments with smooth glass and realistic view for precise laser operations.
Description
Overview
Amuse Tech Solutions driver laser is a single-line LiDAR developed for medium and low-speed scenarios. The industrial design is exquisite and compact, making the product small, light in weight, and high in performance. It supports ultra-high frequency sampling and optional angular resolution and achieves zero blind spots within the detection range.
Features
- High light environment experiment
- Realistic view of smooth glass
Technical Specifications
| Scanning Principle | Mechanical Rotation |
| Range Accuracy | ±2 |
| Range Principle | TOF |
| Protection Distance
|
≥25, 70% reflectivity |
| ≥15, 10% reflectivity | |
| Range | 0 to 25 |
| Horizontal Resolution | 0.1°; 0.25°; 0.25°; 0.25° |
| Horizontal FOV | 270° |
| Data Sample Rate | 36 kHz; 28.8 kHz; 36 kHz; 43.2 kHz |
| Distance Resolution | 1 |
| Rotating Frequency | 10 Hz; 20 Hz; 25 Hz; 30 Hz |
| Laser Class | Class 1 Eye Safe |
| Wavelength | 940 nm |
| Environmental Protection | IP 65 |
| Operating Temperature | -13 °F to 140 °F (-25 °C to 60 °C) |
| Operating Voltage | 9 V to 36 V |
| Storage Temperature | -40 °F to 167 °F (-40 °C to 75 °C) |
| Power Consumption | ≤2 W |
| Dimension | 2.3 in x 2.3 in x 3.1 in (60 mm x 60 mm x 80 mm) |
| Weight | 0.3 lb (160 g) |
