Description
Technical Specifications
| Network | Wired LAN |
| E1 Interface Standard | Comply with protocol G.703 |
| E1 Interface Rate | 2048 Kbps ± 50ppm |
| Ethernet Interface Rate | 10/100/1000 Mbps half/full duplex auto-negotiation |
| Ethernet Interface Standard | Compatible with IEEE 802.3, IEEE 802.1Q (VLAN) |
| Power Supply | AC 180V to 260V; DC -48V; DC +24V |
| Storage Humidity | 5% to 95% (no condensation) |
| Color | Black |
| Interface Rate | n*64Kbps ± 50ppm |
| Interface Code | HDB3 |
| E1 Impedance | 75Ω (unbalanced), 120Ω (balanced) |
| Jitter Tolerance | In accordance with protocol G.742 and G.823 |
| Allowed Attenuation | 0 dBm to 6 dBm |
| MAC Address Capability | 4096 |
| Connector | RJ45, supports Auto-MDIX |
| Power Consumption | ≤ 10 W |
| Storage Temperature | -40°F to 176°F (-40°C to 80°C) |
| Working Humidity | 5% to 95% (no condensation) |
| Working Temperature | 14 °F to 122 °F (-10 °C to 50 °C) |
| Product Size | 8.50 in × 5.51 in × 1.22 in (21.6 cm × 14 cm × 3.1 cm) |
