Decoupling Network with Multi Language User Support – Amuse Tech Solutions
EFT Burst testers assess equipment performance against fast transient interference, with built-in coupling networks and IEC compliance.
Description
Features
- IEC/EN 61000-4-4 Compliance
- 7 in Touch Panel Display
- Multi-language User Support
- Built-in Self-Test Program
Technical Specifications
| Pulse Polarity | Positive/ negative/ alternating |
| Frequency | 1 KH to 1.2 MHz ±10%, continuous adjustable |
| Running Time | 1 to 9999s, continuous adjustable |
| Pulse Number | 1 to 255, continuous adjustable |
| Phase Angle | 0 to 359°synchronous, asynchronous, or automatic |
| Output Voltage | 0.1 to ±5 KV |
| Internal Resistance | 50 Ω ±10 % |
| Pulse Front Edge | 5 ns ±30 % |
| Pulse Width | 50 ns ±30 % (50Ω load),
35 ns to 150 ns (1kΩ load) |
| Burst Period | 0.15 to 99.99s, continuous adjustable |
| Coupling/ Decoupling Network | Built-in, single-phase three-wire, 16 A
(customer specific on demand) |
| Power Supply | AC 220 V ±10% 50/ 60 Hz |
| Ambient Temperature | 59 ℉ to 95 ℉ (15 ℃ to 35 ℃) |
