Cable Fault Test with Adaptive Noise Reduction – Amuse Tech Solutions
Advanced cable continuity tester with acoustic pinpointing, noise reduction, and high accuracy for effective and reliable cable diagnostics.
Description
Features
- Precise signal detection
- Adaptive noise reduction
- Long battery life
- High-contrast LCD display
- Compact and lightweight
Technical Specifications
| Bandwidth (Acoustic Channel) | All-pass: 80 Hz to 1500 Hz Low-pass: 80 Hz to 400 Hz High-pass: 200 Hz to 1500 Hz Band-pass: 150 Hz to 600 Hz |
| Signal Gain | ≥ 80 dB |
| Accuracy | 0.33 ft (0.1 m) |
| Noise Reduction Modes | Noise Reduction / No Noise Reduction / Adaptive Reduction |
| Magnification | > 80 dB |
| Battery | Built-in 3.7 V, 6700 mAh Li-ion |
| Continuous Work Time | Above 9 hours |
| Charger Input | 100 Vac to 242 Vac ±10% |
| Display | 800 x 470 dot LCD, semi-gloss for sunlight visibility |
| Operating Environment | Temperature: 14°F to 104°F (-10°C to +40°C) Humidity: 5 to 90 % RH Elevation: <14,764ft (<4500m) |
| Size | 9.06 in x 5.0 in x 2.17 in (23 cm x 12.7 cm x 5.5 cm) |
| Weight | Main Unit: 2.2lbs (1kg), Sensor: 3.1lbs (1.4kg) |
