Cable Fault Detector with High Fault Accuracy and Versatility – Amuse Tech Solutions
Handheld TDR offering precise fault detection, suitable for metallic cable analysis, with a color display and ergonomic design for efficiency.
Description
Features
- High Fault Accuracy
- Versatile Cable Analysis
- Compact and Ergonomic Design
- Color Backlit Display
Â
Technical Specifications
| Display | 3.5-inch Color Backlit LCD Display |
| Fault Location Accuracy | Approximately 1% of the Selected Range |
| Dead Zone | 1.6 Feet (0.5 Meters) |
| Maximum Range | 19,000 Feet (6,000 Meters) |
| Minimum Display Range | 23 Feet (7 Meters) |
| Range Settings | 11 Manual Configurations |
| Output Impedance | Selectable 25, 50, 75, and 100 ohms |
| Output Pulse Width | 3 ns to 3 ms, Automatically Adjusted Based on Range |
| Scan Rate | 2 Scans Per Second |
| Batteries | Six AA (LR6/R6) Alkaline or NiMH Rechargeable Batteries |
| Typical Battery Life | 12 Hours of Continuous Operation with Alkaline Batteries |
| Voltage Protection | 600V AC Category III, 300V AC Category IV (with Blocking Filter), 250V AC for Other Connectors |
| Selectable Power Down | 1, 3, 5, 10, or 15 Minutes, or Disabled |
| Adjustable VoP | Adjustable from 1% to 99% |
| Water and Dust Resistance | IP54 Rated |
| Operating Standards | Complies with EMC BS/EN 61326-1 |
| Dimensions | 9.8 in x 4 in x 2.2 in (25 cm x 10 cm x 5.5 cm) |
| Weight | 1.3 lb (0.60 kg) |
| Operating Temperature | 14°F to 122°F (-10°C to 50°C) |
| Storage Temperature | -4°F to 158°F (-20°C to 70°C) |
