Breath Detection Microwave Motion Sensor Zigbee Precision Light Sensor – Amuse Tech Solutions
Advanced Breath Detection Microwave Motion Sensor with Zigbee, precision, and integrated light sensor for accurate environmental monitoring.
Description
Overview
Amuse Tech Solutions Breath Detection Microwave Motion Sensor is the human presence detection sensor radar module based on 5.8 GHz frequency modulated continuous wave (FMCW), which is used to detect human movement, micro-movement, breathing signals. And the overall power consumption can reach 20 MA. It provides measured range information and can avoid false triggers and interference outside the set range better.
Features
- Breath Detection Microwave Motion Sensor
- Live Version Supporting Motion
- High-Precision
- Reserve Light Sensor
Technical Specifications
|
RF Parameter |
Certification Standards | FCC/CE/SRRC/RoHS |
| Frequency Range | 5.725 GHz to 5.875 GHz | |
| Transmit Power | -4 dBm | |
| Antenna | Built-in; Flat Antenna | |
|
Hardware Parameter |
Data Interface | GPIO/UART |
| Operating Voltage | 5 V | |
| Operating Current | 20 mA | |
| Operating Temperature | -40 °F to 185 °F (-10 ℃ to +55 ℃) | |
| Storage Temperature | -40 °F to 302 °F (-40℃ to 150 ℃) | |
| Humidity | <85% | |
|
Default Parameter |
Power-On Self-Test Time | 2 s |
| Sensing Output Level | 5 V | |
| Silent Output Level | 0 V | |
| Sensing Output Time | 30 s | |
| Movement Induction Distance | About 78.74 in (2000mm) | |
| Breath Induction Distance | About 78.74 in (2000mm) | |
| Micro-Movement Induction Distance | About 78.74 in (2000mm) | |
| Setting Parameter Method | UART or IO | |
| 2 Dimension | 0.78 in x 0.78 in (20 mm x 20 mm) | |
