AT Command Zigbee Wireless Bluetooth Mesh Support for Low-power Nodes Kit – Amuse Tech Solutions
Efficiently manage low-power nodes with our AT Command Zigbee Wireless Kit, featuring Bluetooth Mesh support for seamless connectivity and control.
Description
Overview
Amuse Tech Solutions AT Command ZigBee is optimized for low power wireless communication with on‐chip dual image Over the Air Download (OAD) support in Building automation (wireless sensors, lighting control, beacons), asset tracking, medical, retail EPOS (electronic point of sale), ESL (electronic shelf label), and Personal electronics (toys, HID, stylus pens) markets.
Features
- Full qualified Bluetooth software protocol stack
- Bluetooth mesh support for low-power nodes
- Zigbee protocol stack in the Software Development Kit
- Ultra-low standby current (0.7 μA) with RTC and RAM retention for extended battery life.
- Very low average radio current and connection interval
Technical Specifications
| Chipset | Ti: CC2340R52E0RKPR |
| Bluetooth Version | BLE 5.3 |
| I/O | 12 |
| Frequency | 2.4 GHz |
| Flash | 512 KB |
| RAM | 36 KB |
| Power Supply | 1.80 V to 3.80 V |
| TX Power | 8 dBm |
| TX Sensitivity | -102 dBm |
| RX Current (Typical) | 5.30 mA |
| TX Current (Typical) | 12 mA |
| Standby Current (Typ) | 0.70 μA |
| Range | 5511.81 in (140000 mm) |
| Size | 0.47 in x 0.87 in x 0.12 in (12 mm x 22.13 mm x 3.2 mm) |
