Amuse Tech Solutions PoE Gigabit Ethernet Fiber Switch
Amuse Tech Solutions PoE gigabit ethernet fiber switch provides 8 100 m Poe ports and 2 100 m electrical ports and 1 SFP optical port uplink.
Description
Overview
Amuse Tech Solutions PoE gigabit ethernet fiber switch provides 8 100 m Poe ports and 2 100 m electrical ports and 1 SFP optical port uplink. It is an economical small-scale switch, which is widely used in small networks and monitoring systems such as homes and enterprises. Supports IEEE 8023 af and IEEE 8032 at Poe standard can provide up to 30 watts of power to Poe webcam, wireless AP, Internet phone and other point receiving devices through one network cable, especially suitable for occasions where power wiring is inconvenient.
Features
- Uses international famous brand chips
- Provides 8 Poe and 2 uplink ports
- Supports IEEE 8023 af / at Poe Ethernet standard
- Features 2 G backplane bandwidth
- Supports one-click VLAN, long-distance transmission
- Built-in power supply, maximum 120 W
- Includes lightning, surge, short circuit protection
Technical Specifications
| Port | 8 10 / 100base-t Poe portsTwo 10 / 100base-t uplink ports
1 SFP optical port uplink |
| Switching Performance | Backplane bandwidth: 0.00617 lb (2.8 g)MAC address table: 2 K
Support store and forward |
| Standard Protocol | IEEE 802.3, IEEE 802.3 i 10 Base-T, IEEE 802.3 u 100 Base-TIEEE 802.3 x Flow Control, IEEE 802.1 q VLAN
IEEE 802.3 af PoE, IEEE 802.3 at PoE+ |
| Poe | Poe ports: 8DC 48 V, single port MAXIMUM POWER 30 W
Power supply line pair: (1 / 2) +, (3 / 6) – |
| Power Supply | 100 V AC to 240 V AC 50 Hz / 60 Hz inputTotal power: 120 W |
| Indicator Light | P: Power indicator, s: ultra long-distance transmission mode indicator, V: VLAN mode indicatorPOE: port 1 to 8 Poe indicator, link: port 1 to 10 electric port connection indicator |
| Use Environment | Operating temperature: 14 °F to 131 °F (- 10 °C to 55 °C)Storage temperature: – 40 °F to 158 °F (- 40 °C to 70 °C)
Operating humidity: 10% to 90% non-condensing Storage humidity: 5% to 90% non-condensing |
| Weight | 2.20 lb (1 kg) |
| Size | 7.87 in x 4.72 in x 1.73 in (200 mm x 120 mm x 44 mm) |
