Amuse Tech Solutions Media Converters
Amuse Tech Solutions media converters are widely used in Radio and Television, video conferencing,medical teaching,security monitoring and other high-demand industries.
Description
Overview
Amuse Tech Solutions media converters are widely used in Radio and Television, video conferencing, medical teaching, security monitoring and other high-demand industries. They are suitable for SDI video monitoring and long-distance video capture. The series of converter have stable performance, clear picture quality, high stability, and LED status indication which can visually observe the working state of the converter.
Features
- Support button adjustment
- Support special features
- With clock recovery, clock shaping
- Full digital, uncompressed HD fiber transmission
- FC connector
- Pass Pathological test
- Rack-mountable
- Input adaptive, output resolution up to 1080 p at 60 Hz
- Transmission distance is more than 12.42 mi (20 km)
- Single mode fiber, up to 49.70 mi (80 km)
Technical Specifications
| Video | |
| Number of channels | 1 or 2 or 4 or 8 or 16 channels |
| Input or output Connector | BNC 75 Ω |
| Input or output voltage | 1.0 Volt p-p |
| Video Bitrate | Max 3.2 Gb/s |
| Video SDI Standards: 270 Mbps (SD-SDI) | 270 Mbps (SD-SDI) 1.485 Gbps or M(HD-SDI) |
| Audio | |
| Audio connector | XLR |
| Distortion | Ë‚0.05% |
| Audio Level | 16 dBu |
| Fiber Optic | |
| Number of Optical port | 1 |
| Connector | FC |
| Transmission Distance | Multi-mode 0.34 mi (550 m), Single-mode 12.24 mi to 49.7 mi (20 Km to 80 Km) |
| Wavelength: | Multimode: 850 nm or 1310 nm; Single-mode: 1310 nm or 1550 nm |
| Connectors | |
| Video | BNC 75 Ω |
| Fiber Optical | FC |
| Rack power | AC line cord |
| Electrical & Mechanical | |
| Power adaptor | AC 100 V to 240 V |
| Power consumption | <3 W |
| Environmental | |
| Operating Temperature | 23 ℉ to 167 ℉ (- 5 ℃ to 75 ℃) |
| Storage Temperature | 23 ℉ to 185 ℉ (- 5 ℃ to 85 ℃) |
| Relative Humidity | Â 0% to 95% (non-condensing) |
| MTBF | >100,000 hrs |
