Amuse Tech Solutions LoRa Wireless Transceiver
Amuse Tech Solutions LoRa wireless transceiver is multifunctional wireless data transmission transceiver, it adopts LoRa spread-spectrum modulation to transmit, it uses high performance, high reliability, high stability wireless data transmission to solve problems.
Description
Overview
Amuse Tech Solutions LoRa wireless transceiver is multifunctional wireless data transmission transceiver, it adopts LoRa spread-spectrum modulation to transmit, it uses high performance, high reliability, high stability wireless data transmission to solve problems such as the inability to install wiring in the field, and provides high performance and low cost solution for complex environments.
Technical Specifications
| Dual machine switching time | <5 s |
| MTBF | >50000 h |
| Status indication | Panel LED, reflecting the serial port data transmission and reception status |
| Standard protocol | IEC 60870-5-101 / 103 / 104, MODBUS, CDT |
| Special protocol | DNP 3.0 and other over 30 protocols,can be developed according to on site needs |
| Fast pulse group immunity | IEC 61000-4-5, level 3 |
| Surge immunity | IEC 61000-4-2, level 3 |
| Electrostatic immunity | IEC 61000-4-4, level 3 |
| Ambient temperature | -13 ℉ to 158 ℉ (-25 ℃ to 70 ℃) |
| Relative temperature | 5% RH to 95% RH , no condition |
| Storage temperature | -22 ℉ to 167 ℉ (-30 ℃ to 75 ℃) |
