Amuse Tech Solutions LoRa WAN Wireless Smart Controller Data Logger
Amuse Tech Solutions LoRa WAN wireless smart controller data logger.
Description
Overview
Amuse Tech Solutions LoRa WAN wireless smart controller data logger. It is an Ethernet Modbus Data Logger programmable with I and O. It’s built in UPS feature providing user alert of AC power loss. During power loss, operation is backed up by internal rechargeable battery. Its internal 4 MB memory logs to 30000 MB data records, and expandable to 32 GB with SD card. Data can be uploaded to server as fast as 5 seconds interval, or 24 hrs to save power. Programmable data logging intervals start from 1 minute up to 24 hrs.
Features
- Real time GPRS, Ethernet, and SMS data upload
- Integrated 16 bit MCU and Siemens GPRS Ethernet module
- Programmable data input type and high to low alerts
- Customizable data upload and logging intervals
- Easy USB setup via PC software
- Remote setup via GPRS, SMS, or Ethernet
- RS 485 port supports data capture in Modbus protocol
- Supports dynamic domain name or fixed IP, UDP to TCP data transmission
- Flexible AC to DC power with internal battery backup
Technical Specifications
| Power Input | 9 V to 15 V DC |
| Data Upload | On schedule, manual request, alarm triggered |
| Protocol | Ethernet UDP and AMP, TCP, GPRS to UDP and AMP, TCP |
| Display Type | Analog and digital |
| Internal Data Record | Average 30000 records (4 MB) |
| Digital Channel | Alarm Dry Contact |
| Signal Type | 4 mA to 20 mA or 0 V to 5 V DC |
| Alarm Trigger | Digital alarm, AD level high or low power loss |
| Data Logging Interval | Programmable (1 min to 60 min) |
| Data Transmission | GPRS, SMS, Ethernet |
| Output | 5 V DC |
| Pulse Channel | On and off switching |
| Data Upload Interval | Programmable (5 sec to 24 hrs) |
| Temperature Channel | -67 ºF to 257 ºF (-55 °C to 125 °C) |
